Single-Sided Keel Model – KE-S Adjustable Decking Pedestal
Single-Sided Keel Model – KE-S Adjustable Decking Pedestal
Single-Sided Keel Model – KE-S Adjustable Decking Pedestal
Single-Sided Keel Model – KE-S Adjustable Decking Pedestal

Single-Sided Keel Model – KE-S Adjustable Decking Pedestal

Vendor: KEGRET
£28.60
£28.60
Please hurry! Only left in stock
Limited-Time Offers, End in: 151D 8H 23M 0S
Adjusting Height: 20-25 mm
Packaging Quantity: 10 Pcs/Carton
Subtotal: £28.60
10 customers are viewing this product

Free Shipping

Free standard shipping on orders over £200

Personal Customisation.

Please contact customer service
Single-Sided Keel Model – KE-S Adjustable Decking Pedestal

Single-Sided Keel Model – KE-S Adjustable Decking Pedestal

£28.60
Single-Sided Keel Model – KE-S Adjustable Decking Pedestal
Single-Sided Keel Model – KE-S Adjustable Decking Pedestal
Single-Sided Keel Model – KE-S Adjustable Decking Pedestal
Single-Sided Keel Model – KE-S Adjustable Decking Pedestal

Single-Sided Keel Model – KE-S Adjustable Decking Pedestal

£28.60
Adjusting Height: 20-25 mm
Packaging Quantity: 10 Pcs/Carton
Description
Description
x

Rugged, compact and cost-effective pedestal system for raised surfaces. Ideal as adjustable joist supports, durable decking base supports, and precise adjustable decking feet across interior floors, wall cladding and balcony applications.

Key benefits

  • Low total cost with compact components for easy transport and storage.
  • Fast, modular installation for prefabricated & retrofit projects.
  • Height adjustment: 20–90 mm across the series.
  • Safe working load: 500–800 kg .
Adjustable joist supports Decking base supports Adjustable decking feet

Typical applications

  • Interior raised floors & access plenum builds.
  • Ventilated facade / wall batten stand-off framing.
  • Balconies, terraces and roof-deck paving/decking.

Important: Overall load capacity reduces as height extenders are added; ensure at least three threads of engagement between any two threaded parts for safe use. Series data derived from KE-S spec.

Series range & safe load

The KE-S series provides a 20–90 mm adjustment envelope with a typical safe working range of 500–800 kg, depending on model configuration and installation conditions.

Component specifications

Head (Support Cap)

Heights available: 18, 23, 33, 52 mm.
Bearing face Ø 90 mm; thickness 4.0 mm.
Post minor outside Ø (excl. thread) 54.8 mm.

Base

Heights available: 16, 21, 31, 50 mm.
Base plate Ø 90.0 mm; thickness 2.5 mm.
Post: 6 ribs; internal Ø 55.3 mm.
86 mm base with underside relief openings.

Fix Collar

Colour: yellow; height 8.0 mm.

Single-sided keel cover

Support surface diameter: 94.8 mm.

Model configurations & adjustment ranges

Model Components Adjustment range
KE-S-N01 18 mm head + 16 mm base 20–25 mm
KE-S-N02 23 mm head + 21 mm base 25–35 mm
KE-S-N03 33 mm head + 21 mm base 35–45 mm
KE-S-N04 33 mm head + 31 mm base 35–55 mm
KE-S-N05 52 mm head + 50 mm base 54–90 mm

Installation guidance

  1. Prepare a flat, load-bearing substrate; ensure drainage where used for decking or paving.
  2. Select the appropriate model to meet the required finished height within the 20–90 mm envelope.
  3. Maintain a minimum three-thread engagement between components; add fix collars as required.
  4. Distribute loads evenly under joists, tiles or battens. Verify design against the 500–800 kg safe working range.

Whether you specify them as adjustable joist supports for timber or composite frames, decking base supports for terraces and balconies, or adjustable decking feet for rapid levelling, KE-S “Black Bull” delivers precision, durability and British-standard practicality.
